ISO · DIN · ANSI · GB standards
Industrial Fastener & Engineering Hardware Manufacturer
Bolts, screws, nuts, washers, pins, rivets, retaining rings, keys, springs and fittings — every type to international standards, with full dimensional data and fast quotations. Find the exact fastener you need in seconds.
- Full dimensional tables on every product
- Grades 8.8 / 10.9 / 12.9 and stainless A2 / A4
- Quotations answered within one business day
Fasteners by Category
Browse the catalog by category and standard. Every product page lists the full dimensional table, materials, finishes, structured data and a quotation path.
Bolts
Hex, flange, shoul…
View standards →Screws
Socket, countersun…
View standards →Nuts
Hex, thin, flange,…
View standards →Washers
Flat, fender, spri…
View standards →Engineering Reference
Engineering refere…
View standards →Nails
Wire nails and spe…
View standards →Pins
Dowel, spring (rol…
View standards →Rivets
Blind (pop) and so…
View standards →Tools
Hex (Allen) keys a…
View standards →Retaining Rings
External and inter…
View standards →Keys
Parallel and Woodr…
View standards →Springs
Compression, exten…
View standards →Threaded Inserts
Helical wire threa…
View standards →Pipe & Pneumatic Fittings
BSP and NPT pipe-t…
View standards →Bearings & Bushings
Ball, roller, thru…
View standards →Rigging Hardware
Wire rope, thimble…
View standards →Seals
O-ring and related…
View standards →General Components
Source CAD compone…
View standards →Shaft Collars
Set-screw and clam…
View standards →Standoffs & Spacers
Threaded and unthr…
View standards →Anchors & Concrete Fixings
Mechanical and che…
View standards →Why Engineering Hardware
A specialist fastener supply partner built around fast, accurate quotations.
01
Full ISO/DIN range
Bolts to springs to fittings, all to recognized international standards with complete dimensional data.
02
Any material & finish
Carbon steel, alloy steel grades 8.8/10.9/12.9, stainless A2/A4, with zinc, HDG, black-oxide and more.
03
Fast quotations
Submit a request from any product page and get a tailored price and lead time within one business day.
Inside the plant
How your fasteners are made
Every part we ship moves through the same six stages, in our own plant. The controls listed under each stage are the ones that decide whether a fastener meets its class — not marketing copy.
-
01 Cold heading
Wire rod is drawn to size and cold-formed into blanks. Forming rather than cutting keeps the grain flow continuous around the head, which is where a bolt is most likely to fail.
Head dimensions and under-head radius checked at set-up and per shift.
-
02 Thread rolling
Threads are rolled between hardened dies rather than cut. Rolled threads are stronger in fatigue than cut threads and hold pitch and flank angle far more consistently across a batch.
Go / no-go ring gauges to ISO 965 tolerance class 6g.
-
03 Heat treatment
Quench-and-temper brings carbon and alloy steel to the property class ordered — 8.8, 10.9 or 12.9 — with the furnace charge tracked so a finished lot can be traced back to it.
Core hardness and tensile tested per lot to ISO 898-1.
-
04 Surface treatment
Zinc, zinc-nickel, hot-dip galvanizing, black oxide, phosphate and Dacromet, selected against the service environment rather than against the price list.
Coating thickness and neutral salt spray hours to ISO 9227.
-
05 Sorting & inspection
Optical sorting checks every piece for dimension, thread condition and mixed parts, so a carton of M8 contains M8 and nothing else.
Automated 100% sort on critical dimensions, plus AQL sampling.
-
06 Packing & dispatch
Bulk, boxed or bagged to your part numbering, with the material test report and the lot number travelling in the carton rather than arriving by email a week later.
Lot traceability from carton back to the furnace charge.
M1.6–M64
Diameter range
4.8 – 12.9
Property classes
ISO 9001
Quality system
24 h
Quotation turnaround
Free Engineering Calculators
Bench-side tools for working with metric fasteners — bolt length, tightening torque, thread engagement, tap drill, washer sizes and more. Open any tool below.
Bolt Length
Clamp + washers + nut + projection → next standard length.
Thread Engagement
Minimum engagement for steel into steel, aluminium, brass or plastic.
Tightening Torque
T = K·F·d with friction picked from common surface conditions.
Tap Drill & Clearance
Tap-drill diameter and ISO 273 clearance holes.
Washer Size
ISO 7089 normal and ISO 7093 large flat washer dimensions.
Bolt Pattern (PCD)
Chord length and X/Y for every hole on a pitch circle.
Pitch ↔ TPI
Convert metric pitch in mm to threads per inch.
Metric ↔ Imperial
Length, torque, force and pressure converter.
From the blog
All articles →
Fastener Guides & Engineering Notes
Selection guides, standards explained, materials and coatings, torque and installation practice.
Hello world!
Welcome to WordPress…
About Engineering Hardware
A specialist supply partner for ISO and DIN industrial fasteners — built around accurate dimensional data and fast quotations.
We supply bolts, screws, nuts, washers, pins, rivets, retaining rings, machine keys, springs and pipe fittings to international standards. Every product page lists the full dimensional table, materials and finishes, structured data and a single-click path to a quotation — so the engineer specifying the part finds what they need without leaving the page.
Our team responds to inquiries within one business day. Specifications include the standard, material, finish, lead time and price, so you can move from selection to purchase in one conversation.
240+Standard items across 21 categories
2200+Size / material / standard guides
15Free engineering calculators
1 dayQuote turnaround
Contact Us
Send a quote request from any product page, or reach the team directly.
Hours
Monday – Friday
9:00 – 18:00 your local time
Quote requests
Use the fastener finder or any product page's quote form — typically answered within one business day.
